MA-3600VZ Service Manual
Parts 5-20
130366-1 Rev. A
©2000 Crown International, Inc.
Q43323-7
VZ switch PWA on D 8589-0 PWB. For schematic
see J0561-1.
Bridge PWAs: Used with Q43323-7 VZ Switch PWA
Only
Q43411-0
Channel 2 bridge PWA on D 8870-4 PWB. For
schematic see J0699-9.
Q43412-8
Channel 1 bridge PWA on D 8869-6 PWB. For
schematic see J0699-9.
