Parts 5-7
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Item Quantity Description Part # (CPN)
5.3.3 Front Assembly
Refer to Figure 5.3 for Exploded View
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Foam Filter
Screw, #8 x 1.00 Type AB Flat HD
Nylon Spacer
Grille Clip
Bottom Cover
Knob
Overlay
Display Panel
Handle
Panel Cap
Screw, #6-32 x .75 FLTHD TT
End Cap
Screw, 8-18 x 1.375 PNHD
Screw, 4-40 x .37 Taptite Pan
Display PWA
5KOhm Linear 31 Detent Pot 15MM Shaft
Screw, 6-32 x .25 RDHD
Washer, #6 Int Star
Screw, 6-32 x ,437 Socket Cap
Switch, DPST Pushbtn 6A 250VAC
Chassis
Lower Grille Extrusion
Push Button, .75 Threaded
Panel Cap Spacer
Self-Stick Rubber Feet
Insulator, 11 x 15 Transformer
.5 x .136 Nylon Washer
Velcro Tape
Grille Assembly (includes Bottom Cover)
2
2
2
2
1
2
1
1
2
2
2
2
2
2
1
2
3
3
3
1
1
1
1
2
5
1
2
8
1
D7696-4
A10103-10816
A10101-12
A10173-1
F12609-8
D6265-9
D 9148-4
F12887-0
D8048J6
D8049J4
C10258-9
D8052J8
A10086-10824
C5961-5
See Section 5.4
C7280-8
A10086-10604
A10094-3
A10092-20607
C10180-5
see Section 5.3.1
D8752-4
D6013-3
F12647-8
C3342-0
D8249-1
A10101-5
D5796-6
M46504-3
Note: Old style grilles with the one-piece
fi lter behind the grille are no longer available.
If an older amplifi er needs a new grille, the
only option is to convert it to the new style
by ordering CPN #M46504-3, which includes
the bottom cover, grille extrusion, fi lters and
necessary hardware. New grilles will not fi t
onto old bottom covers.
