Crown Macro-Tech MA-3600VZ Service Manual

Parts 5-11
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Item Quantity Description Part # (CPN)
5.3.5 Channel 1 (Left) Bi-Level Switch Assembly
Refer to Figure 5.5 for Exploded View
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Not Pictured
Not Pictured
7
1
2
4
1
4
4
2
2
1
4
4
2
3
4
1
1
1
Screw, 6-32 x .25 Socket Cap
PWA, B-L Switch
Clamp, TO-220 Bi-Level
#6 Int Star Washer
Left Shelf
Screw, 4-40 x .25 RDHD
#4 Int Star Lockwasher
#8 Belleville Washer
8 x 32 Hex Nut
PWA, CH1 B-L Bridge
Screw, 6.32 x.25 Ind Hex
Washer, #6 Int Star
Bridge, 35A 400V
Nylon Hex Spacer
Capacitor, 6900uF 100V Elec.
Insulator, 1.5 x .75 (Orange)
Insulator, 1.5 x 1.25 (Gray)
Channel 1 Bi-Level Switch Assembly
Note: for units built before September, 1995 use
CPN#M46663-7 Switch Assembly.
A10092-20604
See Section 5.4
D8301-1
A10094-4
Same as #1
125238-1
A10086-10404
A10094-2
A10098-3
A10102-6
See Section 5.4
A10107-70604
A10094-3
C10246-4
A10608-10
D7595-8
C9539-5
D8480-2
M46562-1
