Crown Macro-Tech MA-3600VZ Service Manual

Parts 5-13
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Item Quantity Description Part # (CPN)
5.3.6 Channel 2 (Right) Bi-Level Switch Assembly
Refer to Figure 5.6 for Exploded View
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Not Pictured
Not Pictured
1
1
7
2
4
4
2
1
2
2
4
4
4
4
3
1
1
1
Right Shelf
PWA, B-L Switch
Screw, 6-32 x .25 Socket Cap
Clamp, TO-220 Bi-Level
#6 Int Star Washer
Capacitor, 6900uF 100V Elec.
Bridge, 35A 400V
PWA, CH2 B-L Bridge
#8 Belleville Washer
8 x 32 Hex Nut
Screw, 4-40 x .25 RDHD
#4 Int Star Lockwasher
Screw, 6.32 x.25 Ind Hex
Washer, #6 Int Star
Nylon Hex Spacer
Insulator, 1.5 x .75 (Orange)
Insulator, 1.5 x 1.25 (Gray)
Channel 2 Bi-Level Switch Assembly
Note: for units built before September, 1995 use
CPN #M46662-9 Switch Assembly.
125238-1
See Section 5.4
A10092-20604
D8301-1
A10094-4
Same as #3
D7595-8
C10246-4
See Section 5.4
A10098-3
A10102-6
A10086-10404
A10094-2
A10107-70604
A10094-3
A10608-10
C9539-5
D8480-2
M46561-3
