Crown Macro-Tech MA-3600VZ - Page 43

Parts 5-23
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Capacitors
C01 A10434-473JD .047µF
C02 C 8426-6 .1µF
C03 C 8426-6 .1µF
C04 C 6806-1 .01µF
C05 C 6806-1 .01µF
C06 C 6806-1 .01µF
C07 C 6807-9 .001µF
C08 C 8577-6 68pF
C10 C 6807-9 .001µF
C12 C 6809-5 220pF
C13 C 8963-8 .47µF
C15 C 6809-5 220pF
C16 C 8426-6 .1µF
Diodes
D01 C 2851-1 1N4004
D02 C 2851-1 1N4004
D03 C 2851-1 1N4004
D04 C 2851-1 1N4004
D05 C 8383-9 MR822
D06 C 8383-9 MR822
D07 C 8383-9 MR822
D08 C 8383-9 MR822
D15 C 2851-1 1N4004
D16 C 2851-1 1N4004
Inductors
L00 D 7701-2 2.5µH
L01 C 3510-2 470µH
L02 C 3510-2 470µH
Transistors
Q00 C 4647-1 TIP47
Q01 C 8159-3 2SC4029
Q05 C 8186-6 2SA1553
Q12 C 8159-3 2SC4029
Q16 C 8186-6 2SA1553
Q17 C 8508-1 2SC3298B
Q18 C 4647-1 TIP47
Q19 C 8509-9 2SA1306B
Resistors
R00 A10266-1311 130
R01 A10266-1011 100
R02 A10266-8R22 8.2 .5W
R03 C 3583-9 .33 5W
R04 C 3583-9 .33 5W
R05 C 3583-9 .33 5W
R06 C 3583-9 .33 5W
R07 C 3583-9 .33 5W
R08 C 3583-9 .33 5W
R09 C 7779-9 22
R10 A10266-1011 100
R11 C 6625-5 5.6 5W
R12 A10266-2R74 2.7 2W
R13 A10266-1311 130
R14 A10266-2R74 2.7 2W
R15 C 3583-9 .33 5W
R16 C 3583-9 .33 5W
R17 C 3583-9 .33 5W
R18 C 3583-9 .33 5W
R19 C 3583-9 .33 5W
R20 C 3583-9 .33 5W
R21 A10266-8R22 8.2 .5W
R22 C 7779-9 22
R23 C 6844-2 250 POT
R24 A10266-1331 13K
R25 A10266-2221 2.2K
R26 C 6844-2 250 POT
R27 A10266-3911 390
R28 A10266-1331 13K
R29 A10266-5101 51
R30 A10265-10201 102 1%
R31 C 6625-5 5.6 5W
R35 A10266-1R02 1 .5W
R36 A10266-1R02 1 .5W
R37 C 7779-9 22
R38 C 7779-9 22
R39 C 7779-9 22
R40 C 7779-9 22
R41 C 7779-9 22
R42 C 7779-9 22
R43 A10266-5101 51
R44 A10266-2021 2K
R45 A10266-7511 750
Miscellaneous
(4) A10094-2 Lockwasher, #4
(2) C 7481-2 4 Way Tab Conn.
(4) A10608-3 4-40 x 3/8 Standoff
(1) D 8441-4 Fishpaper, 5.5 x 018
(4) A10020-1 4-40 x .25 Capt. Stud
(2) C 9828-2 12 Pin Header
Q43318-7 Output PWA (P10423-5 PWB) Parts List
