Crusader MP 5.0L User Manual

7
L510023-07
Figure 7 Shift Lever Positions - Velvet Drive 5000
Figure 8 Shift Lever Positions - Hurth
Velvet Drive 5000 Series and Hurth
Transmissions
These transmissions are “Full Reversing” with an
8-degree, down-angle output fl ange. This allows a
standard (LH or CCW) rotation engine to be used
for both propeller shaft rotations. Shaft rotation is
determined by shift cable installation at the remote
control (Figures 7 and 8). Transmission gear ratio
and serial number is marked on the transmission
identifi cation plate.
LH
RH
FORWARD
GEAR
FORWARD
GEAR
VELVET DRIVE 5000
TRANSMISSIONS
RH PROP SHAFT ROTATION
LH PROP SHAFT ROTATION
LHRH
FORWARD
GEAR
FORWARD
GEAR
RH PROP SHAFT ROTATION
LH PROP SHAFT ROTATION
HURTH
TRANSMISSIONS
