RPM Cruise Only Twin Engine Synchronization CAN BUS Displays
Engine Side
Dash Side
Engine Speed Control / CAN-Bus Harnesses
Part Number -
RA152007
AB
AB
1
2 3
4 5
6
+ Battery
- Ground
1
2 3
4 5
6
OPTIONAL - Murphy Supplied Equipment See your Distributor/ Dealer for the kit you require.
STARBOARD/ MASTER ENGINE
PORT/ SLAVE ENGINE
GND
Master / Slave
Engine Harness
Part Number -
RA121072C
+ Battery
- Ground
Sync
Cruise
Speed
Cancel
Set
OFF
ON
Syn/Cru
(-)
(+)/Res
Speed
+ Battery
- Ground
RA121091 - 25 FT, Engine to Panel RA121091A - 45 FT, Engine to Panel
Murphy HelmView
OR
Murphy PowerView
NOTE: The above illustration represents a typical twin engine installation using Crusader and Murphy harnesses. Original boat harnesses may be used with the appropriate adapter and FWMurphy equipment may be used without the use of the Crusader Speed Control/CAN Bus harness.
SLAVE
MASTER
Murphy CAN
Bus Instruments
Murphy CAN
Bus Instruments
Crusader Sync-N-Cruz Kit - RF152007
Includes:
Harness - RA121091 - 25 FT, Engine to Panel Control Panel - RA152007
