Crusader MP 5.0L User Manual

24
L510023-07
Sync/Cruise Switch Panel (RA152007)
RA152007
9-28-06
ORN/
GRN
ORN/
BLU
BRN
BLK
BLK BLK
PPL
PPLPPL
BRN
ORN
ORN
LT
BLU/
BLK
LT
BLU/
BLK
RED/
YEL
RED/
YEL
Sync/
Cruise
Speed Speed
(+) /
Resume
SETON
OFF CANCEL (-)
5K
Resistor
Sync
LED
Cruise
LED
Circuit
Board
From
Ignition
To
Ground
Deutsch 12-Way Connector
P/N - DT06-12S
910121138
Cruise
LED
(Ground)
Sync
LED
(Ground)
Cruise
Request
Sync
Request
Speed
Set/
Cancel
Speed
Increment/
Decrement
Note: Panel 12-Way connector plugs directly into the following
Crusader supplied Boat Speed Control Harnesses:
RA121091
RA121091A
***See the following pages for schematics of these harnesses.
