SG250 Ownerās and Service Manual
www.CSCMotorcycles.com
34
Remove the six clutch bolts in an even pattern by unscrewing
each bolt a few turns at a time. Do this in a crisscross
pattern to allow the clutch hub to back out evenly.
Remove the clutch hub to expose the clutch springs.
We recommend replacing the clutch springs when replacing
the clutch. Remove the Circlip that secures the clutch inner
basket.
For reference during reassembly, the Circlip has a sharp-
cornered edge and a radiused edge on opposite sides. The
sharp edge should face away from the motorcycle during
reassembly.
This is the sharp edge.
