CSC SG250 - Page 36

SG250 Owner’s and Service Manual
www.CSCMotorcycles.com
36
The inner portion of the centrifugal oil cleaner is secured by
a castellated nut. This nut is shown by the lower red arrow
on the right in the photo.
Use a castellated nut driver like the one shown here to
remove the nut.
Remove the castellated nut.
Remove the castellated nut.
