Programming Manual 110
Where:
Field Purpose Options Description
n Wizard Number 1 – 5 Wizard Number, 1 to 5
rt1 Port B Baud Rate Valid Rates Valid baud rate for port B
rt2 Port A Baud Rate Valid Rates Valid baud rate for port A
diff Differential Source NONE Autonomous Mode
BEACON-A SBX-2, Automatic Beacon Mode
BEACON-M SBX-2, Manual Beacon Mode
LBAND-A SLX-2, Automatric OmniStar Mode
LBAND-M SLX-2, Manual OmniStar Mode
WAAS SLX-2, WAAS Mode
EXTERNAL External RTCM, Port A Mode
el Elevation Mask 5 – 45 Valid SLX-2 Elevation Mask
age Differential Age 6 – 8100 Maximum Age of Differential
lfreq L-Band Frequency Valid frequency, 0 for auto
lsym L-Band Symbol Rt. Valid symbol rate, auto if lfreq is 0
bfreq Beacon Frequency Valid frequency, 0 for auto
br Beacon Bit Rate Valid bit rate, 0 for auto
12.3 $PCSI,WIZARD,RATES
This command is used to set the Wizard parameters.
The command follows the following format:
$PCSI,WIZARD,RATES,n,gg,gl,gs,st,sv,rm,rr,vt,zd,b95,b96,rtcm
