Chapter 4. Console Port Operation
44
May 2011
To enter the Timeslot Mapping menu, press 4.
Item 1 supports the immediate and local setting of timeslots in this unit. Item 2&3 are both
used to configure a remote ETU-01A, if it is already linked with the local unit by E1. The E1 must
be framed, FAS or CAS, in order to support the remote in-band setting. Item 2 sends the entire
timeslot mapping to the remote unit. Item 3 allows individual setting through in-band management.
To define the Timeslot mapping assignments, press 1.
Edit the timeslots, one-by-one and either assign it to the data port, or make it not connected. Each
timeslot will provide 64Kbps data bandwidth.
<< Define System Parameter >>
1. Timing
2. E1 Line
3. Remote E1 Line
4. Time Slot
5. Data Port
6. Remote Data Port
7. Date & Time
8. Remote Config Function.
9. SNMP Agent Setup
A. Threshold
Enter 1-A or Press "ESC" to previous menu.
<< Define Time Slot Mapping >>
1. Define Time Slot Mapping.
2. Send Time Slot to Far End.
3. Define Remote Time Slot Mapping
Enter 1-3 or Press "ESC" to previous menu.
<< Define Time Slot Mapping >>
TIME SLOT 01
TYPE : Data port
1. NC
2. Data Port
Enter 1-2 or Press "ENTER" to next Time Slot or "ESC" to previous
menu.
