Chapter 4. Console Port Operation
45
May 2011
To view the entire timeslot mapping, use ESC to exit all the way back to the main menu and select
item 1, Display System Status, select item 3 Time Slot.
In the above example, TS01-TS31 are all used. This is obviously an FAS or PCM31 framing
(note TS00 is assigned to Framing). The bandwidth supplied by these 31 time slots is 1984kbps
(31x64kbps).
Return to Time Slot setting, from Main menu select item 2, Define System Parameter
followed by item 4, Time Slot. Continue to set the timeslot mapping assignments, go on to the next
timeslot or ESC. ESC will take us back to the Define Time Slot Mapping menu.
Selecting item 2 will attempt to take the defined time slot mapping for the local unit and send
it to the remote ETU-01A unit. In this way, the bandwidth can be controlled from the local unit.
The E1 must be in SYNC, the framing matched (cannot be unframed) and the remote unit must
already be configured to accept remote assignment.
<< Display Time Slot Mapping >>
SLOT : 00 01 02 03 04 05 06 07
TYPE : Fr * * * * * * *
SLOT : 08 09 10 11 12 13 14 15
TYPE : * * * * * * * *
SLOT : 16 17 18 19 20 21 22 23
TYPE : * * * * * * * *
SLOT : 24 25 26 27 28 29 30 31
TYPE : * * * * * * * *
* : Time slot used . : Time slot not used
Fr: Framing Si: Signaling
Press "ESC" to previous menu.
<< Define Time Slot Mapping >>
1. Define Time Slot Mapping.
2. Send Time Slot to Far End.
3. Define Remot Time Slot Mapping
Enter 1-3 or Press "ESC" to previous menu.
WAIT .........
