Cub Cadet RZT-S Professional Shop Manual

RZT-S
108
To replace the 46” deck belt:
1. Remove the deck as described at the beginning of
this chapter.
NOTE: Removal of the deck is not necessary, but
makes it easier to route the belt around the
spindles.
2. Loosen the idler pulleys enough to allow the belt to
slip between them and the belt keepers.
3. Slide the belt off of the pulleys.
4. Route the new belt around the pulleys.
See Figure 7.8.
5. Tighten the idler pulleys.
6. Install the deck as describe at the beginning of this
chapter.
7. Test run the mower before returning to service.
To replace the 50” deck belt:
1. Remove the deck as described at the beginning of
this chapter.
NOTE: Removal of the deck is not necessary, but
makes it easier to route the belt around the
spindles.
2. Loosen the two rear idler pulleys enough to allow
the belt to slip between them and the belt keepers.
3. Slide the belt off of the pulleys.
4. Route the new belt around the pulleys.
See Figure 7.9.
5. Tighten the idler pulleys.
6. Install the deck as described at the beginning of this
chapter.
7. Test run the mower before returning to service.
w%FDLCFMUSPVUJOH
Figure 7.8
w%FDLCFMUSPVUJOH
Figure 7.9
