Cub Cadet RZT-S Professional Shop Manual

RZT-S
14
Control cable adjustment
To adjust the control cable:
1. Move the throttle lever to the detent between the full
throttle and the choke position.
2. Loosen the clamp that holds the control cable jacket
in position. See Figure 2.17.
3. Slide the cable jacket until the speed control lever
makes contact with the choke lever.
4. Tighten the control cable jacket.
5. Move the throttle lever to the choke position.
6. Verify that the choke is fully closed.
7. Test run the mower in a safe area before returning it
to service.
Figure 2.17
Speed control lever
Control cable clamp
Choke lever
Contact point
www.mymowerparts.com
For Discount Cub Cadet Parts Call 606-678-9623 or 606-561-4983

Cub Cadet RZT-S Specifications

General

Turning Radius	Zero-Turn
Deck Material	Steel
Engine	Kohler
Horsepower	22 HP
Cutting Width	50 in
Transmission	Hydrostatic
Fuel Capacity	3.5 gal
Speed	7 mph
Weight	600 lbs
