Decks and Lift Shaft
119
6. Remove both of the deck lift shaft brackets by remov-
ing the two screws that hold them in place using a 1/
2” wrench. See Figure 7.31.
7. Gently compress the spring arms of the lift bracket
while prying the brackets off of the lift shaft.
8. Snap new lift shaft brackets onto the lift shaft.
9. Install the deck lift shaft by following steps 1 through
6 in reverse order.
NOTE: Do not put grease on the lift shaft or bushings.
Grease will hold dirt and accelerate the wear of the
bushings.
10. Operate the deck through its full range of travel.
11. Check the deck for levelness and pitch.
12. Test run the mower in a safe area before returning it
to service.
Figure 7.31
Lift shaft bracket
Spring arms
