Cube 3d printer User Manual

30
MATERIAL CARTRIDGE INSTALLATION
1. Remove material cartridge from packaging; using scissors cut top portion of bag and remove the cartridge.
2. Tap “Setup” on Cube touch screen then select “load cartridge,” press Next.
3. Remove thumbscrew on the side of the material cartridge. Remove the blue tape from material. Retain screw to re-
install in cartridge when you need to store cartridge again. Press Next to begin the cartridge installation.
18
Tap Here
Remove and
retain screw.
Do not pull material until thumbscrew is removed from cartridge. Doing so will damage cartridge.
Tap Here

Cube 3d printer Specifications

General

Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	Wi-Fi, USB
Supported Materials	ABS, PLA
Technology	Fused Deposition Modeling (FDM)
