8.930-369.0 • 2848 • Rev. 4/13a
OPERATOR’S MANUAL
PARTS WASHER
38
EXPLODED REAR VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.916-077.0 Control Arm Conduit 2848 1
2 8.712-972.0 Hub, Conduit 1-1/2" NPT, Thrd 2
3 8.706-193.0 Elbow, 1-1/2" Galv. 90° 2
4 8.730-382.0 Nipple, 1-1/2" Sch40 x 5-1/2"L 1
5 9.802-778.0 Nut, Whiz Loc 5/16" Flange 12
6 8.713-265.0 Cap-Vinyl Black 1
7 8.915-256.0 Assy, Electrical Box 1
8 8.930-252.0 Cover, Electrical Box 1
9 8.930-331.0 Cover, Heating Element 1
10 8.749-191.0 Heating Element,
9KW/208V/1PH/3PH
(1.043-423.0 ;1.043-421.0) 1
8.712-954.0 9KW/230V/1PH/3PH
(1.043-422.0; 1.043-394.0) 1
8.713-179.0 9KW/460V/3PH (1.043-424.0) 1
8.713-178.0 9KW/575V/3PH (1.043-425.0) 1
11 9.804-094.0 Weatherstrip 1/8 x 1/2 124"
12 8.713-593.0 Thermostat, Snap Disc 180°F,
1 Phase 1
8.713-030.0 Thermostat, Blb & Cpllry 195°F,
3 Phase 1
13 8.706-350.0 Pipe, Cap, 1/2" Galv. 1
14 8.718-794.0 Screw, 10/32" x 3/4", Hex SS 12
15 9.802-791.0 Nut, Cage, 10/32" x 16 Ga 14
16 9.804-510.0 Switch Lid/Door 15 Amp,
Non-Enclosed 1
17 8.930-265.0 Box, Electrical Door Switch 1
18 8.716-377.0
Terminal, Ring Tongue,
14 ab-10
2
19 8.735-007.0 Rod, Door Switch 5/16" x 19.5"
Acrylic 1
20 Label, ETL 1
21 8.706-343.0 Pipe, Barbed/Male NPT 1-1/2"
Galv 1
22 9.804-399.0 Grommet, Pipe Vinyl 1-1/2" 1
23 9.804-375.0 Gasket, Pump Plate 1
24 9.804-376.0 Gasket, Pump Plate Center
Self Adhesive 2
25 8.709-081.0 Clamp, Screw, #28 p/n 6828 2
26 8.749-190.0 Hose -1 1/2" AG 200 8.5"
27 8.713-135.0 Pipe, Barbed/Male NPT 1-1/2" 1
28 8.706-195.0 Elbow, 1-1/2" Female Black 90° 1
29 8.735-005.0 Nipple, 1-1/2" x 2.5" Lg Sch 40 1
ITEM PART NO. DESCRIPTION QTY
30 8.715-421.0 Pump, Scott 5HP 230V 1 PH
(1.043-422.0) 1
8.715-422.0 Pump, 5HP 208/230/460V 3 PH
(1.043-423.0; 1.043-394.0;
1.043-424.0) 1
8.715-424.0 Pump, 5HP 575V 3 PH
(1.043-425.0) 1
8.749-192.0 Pump, Scott 5HP 208V 1 PH
(1.043-421.0) 1
31 9.802-779.0 Nut, 3/8", ESNA, NC 4
32 9.802-807.0 Washer, 3/8" SAE Flat 4
33 9.804-378.0 Latch, Sump Cover 2
34 8.930-275.0 Assy, Sump Cover 10 x 16.5 1
35 8.706-518.0 Float, Poly, Cylindrical,
2-3/4 Dia x 1-3/4" H8-32 1
36 8.930-271.0 Assy, Control Box 1
37 9.802-781.0 Nut, 3/8" Flg Whiz Loc 2
38 8.706-327.0 Plug, 1.5", Pipe, Galv 1
39 8.913-717.0 Strap, Brass Float 1
40 8.718-762.0
Screw, 8-32 x 1/2", M PH RDH Pl
1
41 9.804-119.0 Switch, Mag. Reed Sensor, NC
1
42 9.804-118.0 Switch, Mag. Reed Sensor, NO 1
43 9.804-120.0 Magnet, Reed Sensor Target 1
44 8.718-847.0 Nut, 4-40 KEPS, Zinc 1
45 8.731-134.0 Screw, 4-40 x 1/2" Slotted P/H
M/S Zinc 1
46 9.804-224.0 Decal, Caution (Check Water
Level) 1
47 9.804-223.0 Decal, Operator Install 1
48 9.800-034.0 Label, Clear Lexan 1
49 9.800-016.0 Label, Disco Power Supply 3
50 9.804-352.0 Decal, Danger High Voltage 1
51 9.804-372.0 Decal, Warning, Yellow & Black 1
52 9.804-140.0 Decal, Warning Grade Level,
Wire Temp Rating 1
53 8.915-388.0 Seal, Bulb Type EPDM Side
Profile 48"
54 9.804-297.0 Label, Hour Meter 1
55 8.706-755.0 Bushing, .875" 1
56 8.706-744.0 Plug, Plastic 1" 1
57 9.802-105.0 Plug, 7/8", Hole 2
58 9.802-517.0 Connector, 1/2" L/T, 90° Black 1
59 9.802-515.0 Strain Relief, Strt, LQ Tite 3200 1
To Next Page
