CUDA 2848 - Electrical Panel - 460 V 3 Ph Exploded View Parts List

8.930-369.0 • 2848 • Rev. 4/13a
51
PARTS WASHER
OPERATOR’S MANUAL
ITEM PART NO. DESCRIPTION QTY
1 8.750-864.0 Contactor, 3 Pole, 16 Amps 2
2 8.713-078.0 Fuse, 2 Amp FNM-2 1
3 8.713-086.0 Ground, Lug 2 Hole Alum 1
4 9.804-595.0 End Bracket, Entrelec,
103-002-26 2
5 8.713-080.0 Fuse, Class R 1 Amp 2
6 8.713-061.0 Fuse Block (C3P) 3-Pole 1
7 8.713-061.0 Fuse Block (C3P) 3-Pole 1
8 8.750-873.0 Overload, 5.5-8.5 Amp 1
9 8.713-067.0 Fuse, Class CC 12 Amp 3
10 8.713-063.0 Fuse, Class CC 15 Amp 3
11 8.716-398.0 Terminal Block, Blue Intrelec 9
12 8.716-396.0 Terminal Block, Intrelec 2
13 8.716-402.0 Bridge, Fix, Entrelec 2
14 8.753-367.0 Relay, SPDT 1
15 8.753-368.0 Relay, Base 1
16 8.716-875.0 Transformer, 200VA
230-460V/115V 1
17 8.714-512.0 Terminal Block, 3 Position 1
18 9.800-040.0 Label, Ground Symbol 1
19 8.716-400.0 End Cover Entrelec, Blue 2
20 9.802-457.0 Din Rail, 35 mm 9"
21 8.716-599.0 Terminal, Grounding, Green
w/Yellow 2
22 8.713-697.0 Connector, Elect 6 Pin Male 1
23 8.713-603.0 Connector, Elect 3 Pin Male 2
24 8.713-604.0 Connector, Elect Pin Female 12
ITEM PART NO. DESCRIPTION QTY
25 8.713-656.0 Connector, Elect 3 Pin Female 1
26 8.713-768.0 Connector, Elect Pin Male 3
27 8.931-186.0 Panel, Elect, 2840/2848 1
28 8.716-375.0 Terminal Ring Tongue
RC10-516 2
29 8.718-937.0 Screw, #8 x 3/4" Phillips,
Zinc Plated, Hex Tek 6
30 9.802-798.0 Screw, #10 x 1/2", Tek Hex
Head 6
31 8.716-399.0 End Cover, Entrelec, Gray 2
32 9.802-778.0 Nut, Whizlock, 5/16" Flange 1
33 9.802-775.0 Nut, 1/4 Flange NC 2
34 9.800-024.0 Label, 460V, 3 PH 1
35 9.804-609.0 Marker Blank 18
ELECTRICAL PANEL - 460V 3PH EXPLODED VIEW PARTS LIST
