ITEM NO. PART NUMBER QTY. DESCRIPTION
4 445-006-002 6 NUT,LOCK
3 485-006-001 12 WASHER,SAE FLAT
2 415-006-020 6 CAPSCREW
1 400-012-001 2 MUD FLAP,WAYNE LOGO 18 X 24
8
BY
ECN NUMBER
SYM
DIMENSIONS IN () ARE REFERENCE
ANGULAR ± 1°
2 PLACE DECIMALS ± .06
3 PLACE DECIMALS ± .005
TOLERANCES
(EXCEPT AS NOTED)
DRAWING NO.
DATE
SCALE
CHK'D
DRAWN BY
DATE
DESCRIPTION
7
6
This drawing is loaned to you and is to be returned upon our request.
1
2
3
4
5
This drawing and the information thereon is the property of WAYNE ENGINEERING CORPORATION. It may not be
copied, duplicated, reproduced or used in any way to the detriment of WAYNE ENGINEERING CORPORATION.
ECN RELEASE
00-36295-01-AB
ECN
ECN
ECN
ECN
ECN
ECN
ECN
ECN
00-36295-01-AB
10/07/05
TRIM KIT, NARROW MUD FLAPS, PLS
03022
DAS
1:8
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
3
1
3
2
4
1
24
