7
8
BY
ECN NUMBER
SYM
DIMENSIONS IN () ARE REFERENCE
ANGULAR ± 1°
2 PLACE DECIMALS ± .06
3 PLACE DECIMALS ± .005
TOLERANCES
(EXCEPT AS NOTED)
DRAWING NO.
DATE
SCALE
CHK'D
DRAWN BY
DATE
6
5
DESCRIPTION
This drawing is loaned to you and is to be returned upon our request.
1
2
3
4
This drawing and the information thereon is the property of WAYNE ENGINEERING CORPORATION. It may not be
copied, duplicated, reproduced or used in any way to the detriment of WAYNE ENGINEERING CORPORATION.
ECN RELEASE
DAS
00-38762-02-AB
ECN 04083 DAS 06/19/09
ECN
ECN
ECN
ECN
ECN
ECN
ECN
00-38762-02-AB
04/13/08
VALVE ASSY, ONE OPTION, QUS
04073
1:3
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
ITEM NO. PART NUMBER QTY. DESCRIPTION
13 841-010-010 2 ADAPTER,MALE O-RING,MALE JIC
12 535-004-007 1 CAP, NIPPLE DUST
11 535-004-005 1 NIPPLE, DIANOSTIC
10 863-012-000 2 PLUG, MALE O-RING HEX HEAD,
9 445-005-001 3 NUT,
8 470-031-000 3 WASHER, LOCK
7 415-005-048 3 CAPSCREW
6 842-012-000 1 ELBOW, MALE, O-RING
5 841-012-010 4 ADAPTER, MALE O-RING
4 545-004-038 1 VALVE WORK SECTION W/ STUD KIT
3 841-012-000 1 ADAPTER, MALE O-RING
2 00-36195-00-AB 1 VALVE, TG MANUAL, PLS
1 00-36197-00-OB 1 BRKT, TG VALVE, PLS
1
2
13
4
5
6
11
5
12
MOVE FROM WHERE ITEM 3 IS LOCATED
879
3
10
13
TORQUE TIE BOLTS TO 32 FT-LBS
