3 324
REUSE EXISTING BOLT FROM VALVE
4
NO OPTIONS AND 1 OPTION TAILGATE VALVE
3 24 325
ITEM NO. PART NUMBER QTY. DESCRIPTION
5 445-005-001 1 NUT,
4 470-031-000 2 WASHER, LOCK
3 485-005-002 2 WASHER,STD FLAT
2 415-005-012 2 CAPSCREW
1 00-63162-00-AA 1 COVER WLD, REAR VALVE, QUS
2 OPTION TAILGATE VALVE
8
BY
ECN NUMBER
SYM
DIMENSIONS IN () ARE REFERENCE
ANGULAR ± 1°
2 PLACE DECIMALS ± .06
3 PLACE DECIMALS ± .005
TOLERANCES
(EXCEPT AS NOTED)
DRAWING NO.
DATE
SCALE
CHK'D
DRAWN BY
DATE
DESCRIPTION
7
6
This drawing is loaned to you and is to be returned upon our request.
1
2
3
4
5
This drawing and the information thereon is the property of WAYNE ENGINEERING CORPORATION. It may not be
copied, duplicated, reproduced or used in any way to the detriment of WAYNE ENGINEERING CORPORATION.
ECN RELEASE
00-63163-00-AB
ECN
ECN
ECN
ECN
ECN
ECN
ECN
ECN
00-63163-00-AB
04/25/14
COVER INSTALL, TG VALVE, QUS
05880
DAS
1:4
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
