HOPPER BTM KIT, HARDOX 450, QUS
05030
DAS
00-61110-00-AB
ECN
ECN
ECN
ECN
ECN
ECN
ECN
ECN
00-61110-00-AB
11/16/11
1:12
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
ITEM NO. PART NUMBER QTY. DESCRIPTION
2 00-36113-02-OA 1 PLATE, REAR HOPPER BOTTOM, QUS
1 00-36115-01-OA 1 PLATE, HOPPER BOTTOM, QUS
2
1
USE HARDOX HOPPER BOTTOM PLATES INSTEAD OF
STANDARD HOPPER BOTTOM PLATES
