TURN BACK
7.00 MIN
6
7
1
ARE FLUSH
5
THESE SURFACES
14
17
.19
WINCH PLATE & GUSSETS
8.25
3.25
6.75
28.85
.50
HOSE ROUTING DETAIL
8
16
7
17
19 9
11
10
9
8
10
20
BOTH SIDE OF VALVE
SET TO 1500 TO1600 PSI
12
.19 2-5
6
2
3
5
6
18
7
11
12
4
13
15
8 9
21
10
9 810
17
14
INSTALL .50 BELOW LIGHTBAR,
INSIDE OF LIFT HOOK IS FLUSH
WITH INSIDE OF VERTICAL TUBE
19
9
16
10
1
.25
2
7
8
BY
ECN NUMBER
SYM
DIMENSIONS IN () ARE REFERENCE K
ANGULAR ± 1°
2 PLACE DECIMALS ± .06
3 PLACE DECIMALS ± .005
TOLERANCES
(EXCEPT AS NOTED)
DRAWING NO.
DATE
SCALE
CHK'D
DRAWN BY
DATE
6
5
DESCRIPTION
This drawing is loaned to you and is to be returned upon our request.
1
2
3
4
This drawing and the information thereon is the property of WAYNE ENGINEERING CORPORATION. It may not be
copied, duplicated, reproduced or used in any way to the detriment of WAYNE ENGINEERING CORPORATION.
ECN RELEASE
DAS
00-38470-00-AD
00-38470-00-AD
ECN
ECN
ECN
ECN
ECN
ECN
ECN
ECN 04148 DAS 07/01/09
1:8
12/03/08
03893
WINCH KIT, 4000 LB, PLJR
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
ITEM NO. PART NUMBER QTY. DESCRIPTION
21 00-03311-00-OA 1 HOOK,LIFTING
20 545-004-011 2 RELIEF V 1500PSI WORK-PORT
19 485-008-001 10 WASHER,SAE FLAT
18 415-008-020 4 CAPSCREW
17 00-38473-00-OA 1 PLATE, WINCH MTG, PLJR
16 G10E10E10-042 2 HOSE ASSY,,
15 841-010-010 2 ADAPTER,MALE O-RING,MALE JIC
14 00-38475-00-OA 2 GUSSET, WINCH MTG, PLJR
13 01-48107-00-R 25 CABLE, 7/16 DIA 6 X 37,
12 00-33868-00-OA 1 GUIDE,WINCH,PL
11 638-019-040 1 WINCH,4000 LB
10 445-008-003 10 NUT,STD
9 485-008-002 10 WASHER,LOCK
8 415-808-032 6 CAPSCREW
7 00-38472-00-OA 1 TUBE, WINCH, PLJR
6 00-38853-00-AA 2 PIPE ASSY, CABLE GUIDE, QU
5 00-38854-03-AA 1 GUIDE WLD, RH ROLLER, QUS
4 410-008-000 2 CLAMP,CABLE,
3 638-008-008 1 THIMBLE
2 620-065-000 1 SLING HOOK W/SAFETY LATCH KIT
1 00-38854-04-AA 1 GUIDE WLD, LH ROLLER, QUS
INSTALL WINCH GUIDE SO THAT THERE
IS .06 CLEARANCE WITH THE DRUM
WINCH AND THE WINCH CABLE CAN
NOT SLIDE OUT OF THE WINCH DRUM
CABLE DETAIL
