Curtis 1243GEN2 Manual
35
3 — PROGRAMMABLE PARAMETERS:
Throttle Parameters
Fig. 16, cont.
Effect of adjusting the
Throttle Max parameter
(throttle types 3 and 4).
Throttle Type 3 (0–5k)
Throttle Type 4 (0–5V, wigwag)
0
5V
1.4V
(2.0k
)
3.3V
(5.0k)
100% Throttle Max
40% Deadband
0.5V
(400
)
2.1V
(3.0 k
)
3.0V
(4.5k
)
90% Throttle Max
40% Deadband
90% Throttle Max
10% Deadband
60% Throttle Max
10% Deadband
Notes: Voltages shown are at the pot wiper relative to B-.
For throttle types 1 and 3, the deadband points are
defined in terms of the nominal 5k
pot resistance.
Using a pot of greater or lesser resistance will give
different values for the deadband points.
KEY
100%
Neutral
Deadband
Controller
Output
0%
1.4V
(2.0k
)
0.5V
(400
)
3.0V
(4.5k
)
0
5V
100% Throttle Max
40% Deadband
90% Throttle Max
40% Deadband
90% Throttle Max
10% Deadband
60% Throttle Max
10% Deadband
3.3V
4.5V
0.5V
1.7V
3.3V
4.3V
0.7V
1.7V
2.7V
4.3V
0.7V
2.3V
2.7V
3.7V
1.3V
2.3V
0.2V (0
)
