Curtis 1243GEN2 Manual
65
6 — PROGRAMMER MENUS:
Program Menu
6
PROGRAMMER MENUS
The universal handheld Curtis programmers allow you to program, test, and
diagnose Curtis programmable controllers. For information about 1311 pro-
grammer operation, see Appendix B. If you are using the older 1307 program-
mer, consult your existing documentation if necessary.
Note that depending on the specific 1243GEN2 model you have, some of
the menu items may not appear.
1243GEN2 PROGRAM MENU
VOLTAGE Nominal battery voltage, in volts
M1 DRIVE C/L Mode 1 drive current limit, in amps
M2 DRIVE C/L Mode 2 drive current limit, in amps
M3 DRIVE C/L Mode 3 drive current limit, in amps
M4 DRIVE C/L Mode 4 drive current limit, in amps
M1 BRAKE C/L Mode 1 braking current limit, in amps
M2 BRAKE C/L Mode 2 braking current limit, in amps
M3 BRAKE C/L Mode 3 braking current limit, in amps
M4 BRAKE C/L Mode 4 braking current limit, in amps
M1 ACCEL RATE Mode 1 acceleration rate, in seconds
M2 ACCEL RATE Mode 2 acceleration rate, in seconds
M3 ACCEL RATE Mode 3 acceleration rate, in seconds
M4 ACCEL RATE Mode 4 acceleration rate, in seconds
M1 DECEL RATE Mode 1 deceleration rate, in seconds
M2 DECEL RATE Mode 2 deceleration rate, in seconds
M3 DECEL RATE Mode 3 deceleration rate, in seconds
M4 DECEL RATE Mode 4 deceleration rate, in seconds
THROTTLE DECEL Time for transition to braking mode, in seconds
M1 BRAKE RATE Mode 1 braking rate, in seconds
M2 BRAKE RATE Mode 2 braking rate, in seconds
M3 BRAKE RATE Mode 3 braking rate, in seconds
M4 BRAKE RATE Mode 4 braking rate, in seconds
INT BRAKE RATE Interlock braking rate, in seconds
QUICK START Quick-start throttle factor
TAPER RATE Threshold affecting end of regen during direction reversal: 1 to 20
M1 MAX FWD SPD Mode 1 maximum forward speed, as % drive output
M2 MAX FWD SPD Mode 2 maximum forward speed, as % drive output
M3 MAX FWD SPD Mode 3 maximum forward speed, as % drive output
M4 MAX FWD SPD Mode 4 maximum forward speed, as % drive output
M1 MAX REV SPD Mode 1 maximum reverse speed, as % drive output
