Curtis 1243GEN2 Manual
69
1243
GEN2 MONITOR MENU
THROTTLE % Throttle reading, as % of full throttle
FIELD CURRENT Motor field current, in amps
ARM CURRENT Motor armature current, in amps
FIELD PWM Motor field applied duty cycle, as %
ARM PWM Motor armature applied duty cycle, as %
BDI % Battery state of charge, as % of full charge
LOAD VOLTAGE Load sensor voltage, in volts
BATT VOLTAGE Battery voltage across the capacitors, in volts
MOT RES x10 mΩ Motor field winding resistance, in 10-milliohm units
HEATSINK TEMP Heatsink temperature, in °C
TOT SRVC X25 Total service hours, multiple of 25
+TOT SRVC Total service hours, in hours
TRAC SRVC X25 Total traction hours, multiple of 25
+TRAC SRVC Total traction hours, in hours
FORWARD INPUT Forward switch: on/off [neutral switch for Type 4 throttle]
REVERSE INPUT Reverse switch: on/off
MODE INPUT A Mode Select 1 switch: on/off
MODE INPUT B Mode Select 2 switch: on/off
INTERLOCK Interlock switch: on/off
EMR REV INPUT Emergency reverse switch: on/off
MAIN CONT Main contactor: on/off
AUX DRIVER Auxiliary driver: on/off
SYS MODE Operating mode: 0–6
[0=neutral, 1=drive, 2=regen, 3=regen taper, 4=field reversal,
5=aux driver Off, 6=disable (major fault)]
6 — PROGRAMMER MENUS:
Test/Monitor Menu
Note: If you are using the older 1307 programmer,
the 1311’s Monitor Menu is called the Test Menu.
