Program Menu Notes
1
Throttle types (for detail, see Throttle Wiring in Section 2)
Type 1: 5kΩ–0 potentiometers
Type 2:
single-ended 0–5V, 3-wire pot, current source, and electronic throttles
Type 3: 0–5kΩ potentiometers
Type 4:
wigwag 0–5V and 3-wire pot throttles
2
HPD types (for detail, see Section 3: Programmable Parameters, page 41)
Type 0: no HPD
Type 1: HPD fault unless KSI
and interlock inputs are received before a
throttle request >25%
Type 2: HPD fault unless KSI input is received before a throttle request >25%
3
SRO types (for detail, see Section 3: Programmable Parameters, page 42)
Type 0: no SRO
Type 1: SRO fault unless KSI + interlock inputs are received before a direction
is selected
Type 2: SRO fault unless KSI + interlock inputs (in that order) are received
before a direction is selected
Type 3: SRO fault unless KSI + interlock +
forward inputs received in that
order; a reverse input can be received at any point in the sequence.
4
Auxiliary driver types (for detail, see Table 3, page 30)
6 — PROGRAMMER MENUS:
