Curtis 1243GEN2 Manual
67
ADJ HRS LOW Hourmeter preset low byte: 0–99
ADJ HRS MID Hourmeter preset middle byte: 0–99
ADJ HRS HIGH Hourmeter preset high byte: 0–99
SET TOTL HRS Apply preset values to total hourmeter: On or Off
SET TRAC HRS Apply preset values to traction hourmeter: On or Off
HOURMETER TYPE Total hourmeter is default display: On or Off
SRVC TOTL HRS Total service timer setting, in hundreds of hours
SRVC TRAC HRS Traction service timer setting, in hundreds of hours
SRVC TOTL Reset total service timer: On or Off
SRVC TRAC Reset traction service timer: On or Off
DIS TOTL HRS Total disable timer setting, in hours
DIS TRAC HRS Total traction timer setting, in hours
TRAC FAULT SPD Max. drive speed if disable timer expires, as %
BDI LIMIT SPD Max. drive speed upon BDI disable, as %
WARM SPEED Max. drive speed if Mot Wrm resistance exceeds setpoint, as %
MOT WRM x10 mΩ Field resistance setpoint for Warm Speed, in 10-milliohm units
MOT HOT x10 mΩ Field resistance at which no drive output, in 10-milliohm units
MOTOR Ω COMP Enable cutback/cutoff response to motor overtemp.: On or Off
MAX REV REGEN Max. intk braking regen current fr. rev., max. load, in amps
MAX FWD REGEN Max. intk braking regen current fr. fwd., max. load, in amps
MIN REV REGEN Max. intk braking regen current fr. rev., min. load, in amps
MIN FWD REGEN Max. intk braking regen current fr. fwd., min. load, in amps
MAX LOAD VOLTS Voltage on load sensor for max. regen current, in volts
MIN LOAD VOLTS Voltage on load sensor for min. regen current, in volts
INT BRAKE DLY Delay before E-M brake applied after intk switch opens, in secs
FAULT CODE Fault code: On or Off
EM BRAKE PWM Enables modulation of brake driver output: On or Off
FIELD CHECK Fault will register if open detected in field: On or Off
PUMP METER Enables use of Pin 2 as input for a pump hourmeter: On or Off
6 — PROGRAMMER MENUS:
Program Menu
Program Menu, cont’d
