Curtis 1243GEN2 Manual
66
6 — PROGRAMMER MENUS:
Program Menu
Program Menu, cont’d
M2 MAX REV SPD Mode 2 maximum reverse speed, as % drive output
M3 MAX REV SPD Mode 3 maximum reverse speed, as % drive output
M4 MAX REV SPD Mode 4 maximum reverse speed, as % drive output
CREEP SPEED Creep speed, as % drive output
THROTTLE TYPE Type of throttle input
1
THRTL DEADBAND Throttle neutral deadband, as %
THROTTLE MAX Throttle input req’d for 100% drive output, as %
THROTTLE MAP Drive output at 50% throttle input, as %
FIELD MIN Minimum field current, in amps
FIELD MAX Maximum field current, in amps
FLD MAP START Armature current at which field map takes effect, in amps
FIELD MAP Field current map setting, as %
CURRENT RATIO Current ratio: factor of 1, 2, 4, or 8
M1 RESTRAINT Mode 1 restraint braking, in amps
M2 RESTRAINT Mode 2 restraint braking, in amps
M3 RESTRAINT Mode 3 restraint braking, in amps
M4 RESTRAINT Mode 4 restraint braking, in amps
LOAD COMP Load compensation: 0 to 25% drive output
HPD High pedal disable (HPD) type
2
SRO Static return to off (SRO) type
3
SEQUENCING DLY Sequencing delay, in seconds
MAIN CONT INTR Main contactor uses interlock input: On or Off
MAIN OPEN DLY Main contactor open delay: On or Off
CONT DIAG Contactor diagnostics: On or Off
AUX TYPE Auxiliary driver type
4
AUX DELAY Auxiliary driver open delay, in seconds
EMR REV C/L Emergency reverse current limit, in amps
EMR REV CHECK Emergency reverse wiring check: On or Off
EMR DIR INTR Emergency reverse direction interlock: On or Off
VARIABLE BRAKE Variable braking: On or Off
ANTI-TIEDOWN Anti-tiedown: On or Off
POT LOW FAULT Pot Low fault: On or Off
FULL VOLTS Voltage considered 100% state of charge, in volts
EMPTY VOLTS Voltage considered 0% state of charge, in volts
RESET VOLTS Voltage at which state of charge resets to 100%, in volts
BATTERY ADJUST BDI algorithm adjustment to compensate for battery capacity, in secs
BDI LOCKOUT Fault 2 output high when BDI%=0: On or Off
BDI DISABLE Battery s-o-c <1% invokes BDI Limit Speed: On or Off
