Return to TOC Curtis 1239E-1269E Manual, os 37.0 RevA – May 2021
2 — INSTALLATION AND WIRING
pg. 9
Pin Name Description
Related VCL*
Function References
1 KSI
Keyswitch input. Provides logic power
for the controller and power for the
coil drivers.
Keyswitch_Voltage
2 Prop. Driver
Proportional driver. This is a coil driver
with current control capability typically
used for a proportional valve on a
hydraulic manifold. Can also be used as a
digital input.
Automate_PWM()
Put_PWM()
Automate_
Frequency_Output()
Frequency_
Output_Duty_
Cycle()
Sw_13
PWM5
PD_Current
PD_Output
PD_Throttle
VCL_PD_Throttle
3 Driver 4
Generic driver #4; can also be used
as a digital input. Has low frequency
PWM capabilities.
Automate_PWM()
Put_PWM()
Sw_12
PWM4
PWM4_Output
4 Driver 3
Generic driver #3; can also be used as
a digital input. Has low frequency PWM
capabilities. Typically used for external
precharge relay.
Automate_PWM()
Put_PWM()
Sw_11
PWM3
PWM3_Output
5 Driver 2
Generic driver #2; can also be used
as a digital input. Has low frequency
PWM capabilities and a slightly higher
current rating. Typically used for
electromagnetic brake.
Automate_PWM()
Put_PWM()
Sw_10
PWM2
PWM2_Output
6 Driver 1
Generic driver #1; can also be used
as a digital input. Has low frequency
PWM capabilities. Typically used for
main contactor.
Automate_PWM()
Put_PWM()
Set-Interlock()
Clear_Interlock()
Sw_9
PWM1
PWM1_Output
Interlock_State
Main_State
7 Low Power Ground Ground reference for low power connections.
8
Switch 2
Analog 2
Can be used as generic switch input #2 or
as generic analog input #2. Typically used
as the motor temperature analog input.
Sw_2
Analog2_Input
Motor_Temperature
9 Switch 3
Generic switch input #3. Typically used as
the interlock switch.
Sw_3
10 Switch 4 Generic switch input #4.
Sw_4
11 Switch 5 Generic switch input #5.
Sw_5
12 Switch 6 Generic switch input #6.
Sw_6
13 Coil Return
This is the coil return pin (at KSI potential)
for all the contactor coils.
14 Switch 16 Generic switch input #16.
Sw_16
15 Throttle Pot High
Pot high connection for a 3-wire
throttle pot.
Table 2 Low Power Connections
* The related VCL columns are vital when writing VCL code (see Chapter 10). VCL “functions” are used to access the various I/Os; VCL “references” are
predefined names for specific pins. Refer to the OS SysInfo file for specific VCL functions, controller system variables, usage, and CAN Object IDs.
