20
Curtis 1244 Manual, Rev. E
2 — INSTALLATION & WIRING: Misc. Features
not resumed until neutral (no direction) is selected or until the interlock switch
is cycled.
CAUTION: e polarity of the F1 and F2 connections will aect the
operation of the emergency reverse feature. e forward and reverse switches
and the
F1 and F2 connections must be configured so that the vehicle drives
away from the operator when the emergency reverse button is pressed.
An optional wire connected directly to the emergency reverse switch
provides for broken wire protection when that feature is enabled by the OEM.
e emergency reverse check feature periodically pulses the emergency reverse
circuit to check for continuity in the wiring. If there is no continuity, controller
output is inhibited until the wiring fault is corrected. e emergency reverse
wiring check wire (see dotted line in Figure 13) should be connected to the
emergency reverse switch terminals and to Pin 22.
For information about the emergency reverse parameters, see Section 3:
Programmable Parameters.
☞
CAUTION
