Curtis MultiMode 1228 User Manual

16
Curtis 1228 Manual, Rev. F
3 — PROGRAMMABLE PARAMETERS
Motor Parameters .............................. p. 17
Main Current Limit
Motor Resistance
Acceleration Parameters .................. p. 17
Max-Speed Forward Accel Rate
Min-Speed Forward Accel Rate
Max-Speed Reverse Accel Rate
Min-Speed Reverse Accel Rate
Gear Soften
Soft Start
Braking Parameters .......................... p. 19
Max-Speed Forward Decel Rate
Min-Speed Forward Decel Rate
Emergency Stop Decel Rate
Max-Speed Reverse Decel Rate
Min-Speed Reverse Decel Rate
Key-Off Decel Rate
Brake Delay
Speed Parameters ............................... p. 20
Max Speed, M1/M2
Min Speed, M1/M2
Max Reverse Speed, M1/M2
Min Reverse Speed
Creep Speed
Push Speed
IR Compensation
Speed Scaler
Throttle Parameters .......................... p. 22
Throttle Input Signal Type
Throttle Autocalibration
Throttle Deadband
Throttle Gain
Ramp Shape (Static Throttle Map)
Fault Parameters ................................ p. 27
High Pedal Disable (HPD)
Brake Faults
Seat Lift Brake Faults
Fault Beep
Other Parameters ............................... p. 28
Seat Lift
Virtual Seat Lift
Beeper Solid
BDI Full Voltage
BDI Empty Voltage
BDI Reset Voltage
Sleep Delay
Tremor Compensation
Individual parameters are described in the
following text in the order they are listed on
this page. They are listed by the abbreviated
names that are displayed in the programmer’s
Parameters Menu. Not all of these parameters
are displayed on all controllers; the list for any
given controller depends on its specifications.
The programmer displays the parameters in
a different order. For a list of the individual
parameters in the order in which they appear
in the Parameters Menu, see Section 6: Pro
-
grammer Menus.
☞
