Curtis 1228 Manual, Rev. F
15
3 — PROGRAMMABLE PARAMETERS
PROGRAMMABLE PARAMETERS
The 1228 controller has a number of parameters that can be programmed by
means of a Curtis programming device. These programmable parameters al
-
low the vehicle’s performance characteristics to be customized to best fit the
needs of individual vehicle operators. For information on programmers, see
Appendix C.
The MultiMode™ feature of the 1228 controller allows operation in two
distinct modes: “Mode 1” and “Mode 2.” These modes can be programmed to
provide two different sets of operating characteristics, which can be useful for
operation in different conditions. For example, Mode 1 could be programmed
such that the vehicle moves slowly for precise, indoor maneuvering and Mode 2
programmed for higher speed, long distance travel outdoors. Three parameters
can be configured independently in the two modes:
M1 maximum speed
M2 maximum speed
M1 minimum speed
M2 minimum speed
M1 maximum reverse speed
M2 maximum reverse speed.
The controller is in Mode 2 when the mode switch is in the On position (input
connected to B+). Leaving the mode input floating or actively switching it Off
(pulling it to B-) puts the controller in Mode 1.
3
