42
Curtis 1228 Manual, Rev. F
1228 MONITOR MENU (not all items available on all controllers)
HEAT SINK TEMP Heatsink temperature, in °C
THROTTLE % Throttle request: 0–100% of range
SPD LIMIT POT Speed limit pot rotation: 0–100%
BATT VOLTAGE Battery voltage across the capacitors
BDI Battery discharge indicator: % of battery charge
MODE INPUT A On = Mode 1; Off = Mode 2
REVERSE INPUT On = reverse is selected
INHIBIT IN On = operation is inhibited
EM BRAKE DRVR On = electromagnetic brake is mechanically released
MAIN CONT On = voltage is applied to main relay coil
MOTOR R Cold motor resistance, in mΩ
PUSH ENABLE IN On = push enable switch is closed
1228 FAULTS AND FAULT HISTORY
This is a list of the possible messages you may see displayed when the programmer
is operating in diagnostics mode. The messages are listed here in alphabetical
order for easy reference.
BRAKE ON FAULT Electromagnetic brake coil open or driver short
BRAKE OFF FAULT Electromagnetic brake coil short or driver open
CURRENT SENSE FAULT A/D current sense voltage out of range
EEPROM FAULT Error in reading EEPROM locations
HPD High pedal disable (HPD) fault
HW FAILSAFE Motor voltage fault
LOW BATTERY VOLTAGE Battery voltage too low
MAIN CONT FLTS Main contactor did not close or did not open
MAIN ON FAULT Main contactor driver failed short
MAIN OFF FAULT Main contactor driver failed open
NO KNOWN FAULTS No known faults
OVERVOLTAGE Battery voltage too high
POWER SECTION FAULT MOSFET driver fault, or shorted motor wiring
PRECHARGE FAULT Capacitor bank voltage < minimum operating voltage
PROC/WIRING FAULT
HPD fault present >10 seconds
SPD LIMIT POT FAULT Speed limit pot input voltage out of range
THERMAL CUTBACK Cutback, due to over-/under-temperature
THROTTLE FAULT 1 Throttle input voltage out of range
6 — PROGRAMMER MENUS: Monitor and Diagnostics Menus
