Curtis 1228 Manual, Rev. F
6 — PROGRAMMER MENUS: Parameters Menu
6
PROGRAMMER MENUS
The universal Curtis programming devices allow you to program, test, and
diagnose Curtis programmable controllers. For information about the program
-
mers, see Appendix C.
The 1228’s programmable parameters are listed below in the order in
which they are displayed by the programming device.
1228 PARAMETERS MENU
(not all items available on all controllers)
MAIN C/L Main current limit for drive and regen braking, in amps
MOTOR R Cold resistance of motor, in milliohms
IR COMP COEFF IR compensation factor: 0–100%
KEY OFF DECEL Deceleration rate when keyswitch is turned off, in seconds
TREMOR COMP Tremor compensation: 1–5
ACCEL MAX SPD Acceleration rate at maximum throttle requests, in seconds
ACCEL MIN SPD Acceleration rate at minimum throttle requests, in seconds
DECEL MAX SPD Deceleration rate at maximum throttle requests, in seconds
DECEL MIN SPD Deceleration rate at minimum throttle requests, in seconds
E STOP Emergency deceleration rate, in seconds
REV ACCEL MAX Reverse accel rate at maximum throttle requests, in seconds
REV ACCEL MIN Reverse accel rate at minimum throttle requests, in seconds
REV DECEL MAX Reverse decel rate at maximum throttle requests, in seconds
REV DECEL MIN Reverse decel rate at minimum throttle requests, in seconds
M1 MAX SPD Mode 1 max. speed with speed pot at max, as % available
M2 MAX SPD Mode 2 max. speed with speed pot at max, as % available
M1 MIN SPD Mode 1 max. speed with speed pot at min, as % available
M2 MIN SPD Mode 2 max. speed with speed pot at min, as % available
M1 REV MAX SPD Mode 1 max. reverse speed with speed pot at max, as % available
M2 REV MAX SPD Mode 2 max. reverse speed with speed pot at max, as % available
REV MIN SPD Maximum reverse speed with speed pot at min, as % available
GEAR SOFTEN Softened torque reversals for accel/decel while moving: 0–100%
SOFT START Softened torque endpoints for accel from zero speed: 0–100%
RAMP SHAPE Throttle map: 20–70%
BDI FULL VLTS Voltage considered 100% state-of-charge, in volts
BDI EMPTY VLTS Voltage considered 0% state-of-charge, in volts
BDI RESET Voltage at which state-of-charge resets to 100%, in volts
SLEEP DLY Delay before sleep mode, in minutes
