Curtis 1228 Manual, Rev. F
41
6 — PROGRAMMER MENUS: Parameters Menu
BRAKE DLY Delay before engaging electromagnetic brake, in seconds
CREEP SPD Creep speed, as % available speed
THRTL TYPE Throttle type
1
THRTL DEADBAND Neutral deadband adjustment, as % of active range
THRTL GAIN Restricted range throttle adjustment: 1–10
THRTL AUTOCAL Wigwag throttle centering utility: On/Off
SPD SCALER Maximum voltage that can be applied to motor, in volts
HIGH PEDAL DIS High pedal disable (HPD): On/Off
FAULT BEEP Horn if HPD or brake fault: On/Off
BEEPER SOLID Pin 16 output continuous rather than pulsed: On/Off
SEAT LIFT Seat lift enable: On/Off
BRAKE FLTS Electromagnetic brake driver/wiring fault check: On/Off
SL BRAKE FLTS Electromagnetic brake fault check in seat lift mode: On/Off
VSL Virtual seat lift enable: On/Off
PUSH SPD Push speed, as % available speed
Parameters Menu Notes
1
Throttle types (see Throttle Wiring in Section 2)
Type 0: wigwag (5kΩ pots or 5V throttles)
Type 1: inverted wigwag (5kΩ pots or 5V throttles)
Type 2: single-ended pots (0–5kΩ)
Type 3: inverted single-ended pots (5kΩ–0)
Type 4: single-ended voltage throttles (0–5V)
Type 5: inverted single-ended voltage throttles (5V–0).
Parameters Menu, cont’d
