APPENDIX A: EMC & ESD DESIGN CONSIDERATIONS
APPENDIX D
INDEX TO PROGRAMMABLE PARAMETERS
The 1228’s programmable parameters are listed alphabetically in Table D-1, along with cross references to the
main entry in the manual. (Note: These parameters are listed in Parameters Menu order in Section 6, page 40.)
Table D-1 PARAMETER INDEX
MIN MAX DESCRIPTION
PARAMETER VALUE VALUE UNITS IN MANUAL
ACCEL MAX SPD 0.2 4.0 seconds page 17
ACCEL MIN SPD 0.2 8.0 seconds page 17
BDI EMPTY VLTS 19.0 24.0 volts page 29
BDI FULL VLTS 23.4 25.0 volts page 29
BDI RESET 0.0 40.0 volts page 30
BEEPER SOLID OFF/ON — page 29
BRAKE DLY 0.0 1.0 seconds page 20
BRAKE FLTS OFF/ON — page 28
CREEP SPD 0.0 10.0 percent page 21
DECEL MAX SPD 0.2 4.0 seconds page 19
DECEL MIN SPD 0.2 8.0 seconds page 19
E STOP 0.2 4.0 seconds page 19
FAULT BEEP OFF/ON — page 28
GEAR SOFTEN 0 100 percent page 18
HIGH PEDAL DIS OFF/ON — page 27
IR COMP COEFF 0 100 percent page 22
KEY OFF DECEL 0.2 4.0 seconds page 20
MAIN C/L
(
*
)
70, 90, 110 amps page 17
MAX SPD, M1 20 100 percent page 20
MAX SPD, M2 15 100 percent page 20
MIN SPD, M1 0 60 percent page 21
MIN SPD, M2 0 100 percent page 21
MOTOR R 0 625 milliohms page 17
PUSH SPD 25 50 percent page 21
REV ACCEL MAX 0.2 8.0 seconds page 18
REV ACCEL MIN 0.2 8.0 seconds page 18
REV DECEL MAX 0.2 4.0 seconds page 19
REV DECEL MIN 0.2 8.0 seconds page 20
REV MAX SPD, M1 15 100 percent page 21
REV MAX SPD, M2 15 100 percent page 21
REV MIN SPD 0 40 percent page 21
RAMP SHAPE 20.0 70.0 percent page 26
SEAT LIFT OFF/ON — page 28
SL BRAKE FLTS OFF/ON — page 28
SLEEP DLY 0 60 minutes page 30
SOFT START 0 100 percent page 18
SPD SCALER 20.0 28.0 volts page 22
THRTL AUTOCAL OFF/ON — page 23
THRTL DEADBAND 6.0 25.0 percent page 23
THRTL GAIN 1.0 10.0 — page 25
THRTL TYPE
(
**
)
0 5 — page 22
TREMOR COMP 1 5 — page 30
VSL OFF/ON — page 29
*
Main C/L min value depends on model: 20 for 1228-24XX; 34 for 1228-25XX & -29XX; and 30 for 1228-34XX.
**
Throttle types: 0=wigwag, 1=inverted wigwag, 2=0–5kΩ, 3=5kΩ–0, 4=0-5V, 5=5V–0.
APPENDIX D: PARAMETER INDEX
D-1
