Mar 2017 Page 89
DATA ACQUISITION FLIGHT RECORDER Type D51615-202-XXX or D51615-
202-XXX-090 with CCU Type D51616-XXXX and CAM Type D51623-XXXX
Installation and Operating Manual with Illustrated Parts
List
Commercial in Confidence
PIM434-I
© Penny & Giles Aerospace Ltd. No part of this work may be reproduced or distributed by any
means without prior permission in writing from the copyright owner.
FUNCTION
37 PIN
CONN
CABLE REQUIREMENTS
PUSH-TO-TEST 30 24 AWG
ERASE SWITCH "C" 31 24 AWG
ERASE SWITCH "A" 32 24 AWG
LIGHTING 28V 33 24 AWG
RESERVED LIGHTING 34 24 AWG
LIGHTING COMMON 35 24 AWG
LIGHTING 5V 36 24 AWG
FDR INHIBIT B 37 24 AWG
Table 11 Cockpit Control Unit Type D51616-2XXX Connector
Details for Dual DAFR Installation Support – Remote Mic
FUNCTION
37 PIN
CONN
CABLE REQUIREMENTS
RESERVED (REMOTE MIC No.2
SHIELD)
1 N.C.
RESERVED (REMOTE MIC No.2 LO) 2 N.C.
REMOTE MIC No.1 BIAS 3 24 AWG SCREENED TWISTED TRIPLE 1
REMOTE MIC No.1 HI 4 24 AWG SCREENED TWISTED TRIPLE 1
REMOTE MIC No.1 SHIELD 5 24 AWG SCREENED TWISTED TRIPLE 1
RESERVED (INTERNAL MIC No.1
BIAS)
6 N.C.
RESERVED (INTERNAL MIC No. 1 HI) 7 N.C.
RESERVED (INTERNAL MIC No.1 HI) 8 N.C.
OUTPUT TO CHANNEL 4 LO 9 24 AWG SCREENED TWISTED PAIR 3
OUTPUT TO CHANNEL 4 HI 10 24 AWG SCREENED TWISTED PAIR 3
CVR FAULT No. 2 11 24 AWG
FDR FAULT No. 2 12 24 AWG
CVR FAULT No. 1 13 24 AWG
FDR FAULT No. 1 14 24 AWG
AUDIO MONITOR No. 2 HI 15 24 AWG SCREENED TWISTED PAIR 2
CHASSIS GROUND 16 22 AWG
DC POWER INPUT (-) 17 24 AWG
DC POWER INPUT (+) 18 24 AWG
FDR INHIBIT A 19 24 AWG
To Next Page
