DATA ACQUISITION FLIGHT RECORDER Type D51615-202-XXX or D51615-
202-XXX-090 with CCU Type D51616-XXXX and CAM Type D51623-XXXX
Installation and Operating Manual with Illustrated Parts
List
Commercial in Confidence
PIM434-I
© Penny & Giles Aerospace Ltd. No part of this work may be reproduced or distributed by any means
without prior permission in writing from the copyright owner.
Recovery of the digitized audio record using such equipment
can be achieved within 2 minutes per channel.
CAUTION:
Recovery of audio can only be performed off aircraft.
1.3.2 Physical and Other Characteristics
Weight
The weight of the unit does not exceed 3.3kg (7.3lb). This
includes the ULB.
Dimensional Limits
255 (L) x 120 (W) x 89 (H) mm, this includes the ULB.
External Finish
To aid location of the DAFR, the case is finished in International
Orange to BS381C colour number 592.
Marking
The DAFR is marked with the following warning in black letters
25mm high:
FLIGHT RECORDER - DO NOT OPEN
ENREGISTREUR DE VOL - NE PAS OUVRIR
Reflective tape is also attached to the external surfaces.
1.3.3 Environmental Conditions
The equipment satisfies the requirements of RTCA DO-160F,
with test categories as shown in Table 3.
SECTION
REQUIREMENT DAFR CATEGORY
4 Temperature/Altitude E1
(1)
4.5.4 Loss of Cooling X
5 Temperature Variation B
6 Humidity B
7 Operational Shock & Crash Safety B
8 Vibration U2 curves F & F1
9 Explosionproofness E
10 Waterproofness W
