Mar 2017 Page 8
DATA ACQUISITION FLIGHT RECORDER Type D51615-202-XXX or D51615-
202-XXX-090 with CCU Type D51616-XXXX and CAM Type D51623-XXXX
Installation and Operating Manual with Illustrated Parts
List
Commercial in Confidence
PIM434-I
© Penny & Giles Aerospace Ltd. No part of this work may be reproduced or distributed by any means
without prior permission in writing from the copyright owner.
Suitable mating connectors and crimp tools for pin inserts for
DAFR and associated equipment are identified in Table 1.
Table 1 Aircraft Mating Connector Details
EQUIPMENT DAFR
DAFR REPLAY
CONNECTOR
CONNECTOR D38999/26FF35SN D38999/20FB35PN
STRAIGHT CABLE
CLAMP
(1)
M85049/38-19A Not required
ELBOW CABLE
CLAMP
(1)
M85049/39-19A Not required
DUST CAP Not required D38999/33 W 11R
CRIMP TOOL M22520/2-01 M22520/2-01
CRIMP TOOL
LOCATOR
M22520/2-07 M22520/2-09
NOTE:
(1) The cable clamp is offered in two styles. The
straight clamp comes as standard.
Bonding
Two pins are allocated within the main connector for bonding
the DAFR chassis to the airframe. Bonding is also achieved
through the equipment mounting feet.
The DAFR has a DC bonding resistance of 25 m at 1 A.
