Curtiss-Wright D51615-202 Series - Figure 14 Data Acquisition

Mar 2017 Page 85
DATA ACQUISITION FLIGHT RECORDER Type D51615-202-XXX or D51615-
202-XXX-090 with CCU Type D51616-XXXX and CAM Type D51623-XXXX
Installation and Operating Manual with Illustrated Parts List
Commercial in Confidence
PIM434-I
© Penny & Giles Aerospace Ltd. No part of this work may be reproduced or distributed by any
means without prior permission in writing from the copyright owner.
Fig/Item
No
Part No
Airline
Part No
Nomenclature
1 2 3 4 5 6 7
Eff
Code
Units
per
Assy
14-
-1 D51615-202-
XXX-090 Iss 1
DATA ACQUISITION FLIGHT
RECORDER
RF
-1A SA112470 KIT, BEACON MOUNTING RF
-1B SA112457 BRACKET ASSEMBLY 1
10 P112281 • BRACKET, BEACON, RH 1
- P112454 • • PLATE, CONNECTING 1
- P112458 • • PLATE, CONNECTING 1
- 435460630
• • SCREW, M4 x 6mm, CSK HD, SS 2
* * *
20 P112298 • FOOT, RETENTION, RH 1
30 250208135 • PIN, ROLL, 1.5mm DIA x 10mm LG 2
ATTACHING PARTS
40 435890001
• • SCREW, M5 x 10mm, BTN, HD
2
50 680150161
• • WASHER, M5, PLAIN
6
60 P112304 • • SCREW, RETENTION 2
* * *
70 P111197 • PLATE, RETENTION 1
80 P112305 • FOOT, RETENTION, LH 1
90 W107841/0530 • SCREW, M5 x 30mm CAP HD, SKT 2
100
W107841/0540 • SCREW, M5 x 30mm CAP HD, SKT 2
110 P112282 • BRACKET, BEACON, LH 1
120 220000084 • BEACON, 90 DAY 1
130 230180180
• SEAL, 0,070mm SECTION,
FLOUROSILICONE
A/R
140 P109643
• LABEL, IDENTIFICATION - OUTER
1
- P109746
• LABEL, IDENTIFICATION - INNER
1
* * *
- 50000039 • TREADLOCK, LOCTITE 222 A/R
- Item Not Illustrated 'AR' As Required 'RF' For Reference Only
