Curtiss-Wright D51615-202 Series - Page 100

Mar 2017 Page 84
DATA ACQUISITION FLIGHT RECORDER Type D51615-202-XXX or D51615-
202-XXX-090 with CCU Type D51616-XXXX and CAM Type D51623-XXXX
Installation and Operating Manual with Illustrated Parts List
Commercial in Confidence
PIM434-I
© Penny & Giles Aerospace Ltd. No part of this work may be reproduced or distributed by any
means without prior permission in writing from the copyright owner.
Airline Nomenclature Eff Units
Fig/Item Part No Part No Code per
No 1234567 Assy
13-
360 435886012 · SCREW, M3 BUTTON HD SKT, SS, 2
5mm LG (VK7766)
* * *
370 P109554 · RAIL, PCB MOUNTING 3
ATTACHING PARTS
380 435886023 · SCREW, M3 BUTTON HD SKT, SS, 4
8mm LG (VK7766)
390 435886025 · SCREW, M3 BUTTON HD SKT, SS, 1
10mm LG
* * *
400 P109879 · RAIL, PCB MOUNTING 3
ATTACHING PARTS
410 480230238 · SPACER, M3, MALE-FEMALE, 2
7mm LG
420 680130110 · WASHER, M3, STD, SS (VK7766) 2
440 435886023 · SCREW, M3 BUTTON HD SKT, SS, 4
8mm LG (VK7766)
* * *
450 P109701 · SUPPORT, PCB 2
460 P109878 · BRACKET, FRONT MOUNTING 1
ATTACHING PARTS
470 435890003 · SCREW, M5 BUTTON HD SKT, SS, 4
12mm LG (VK7766)
* * *
480 W107350 . MOD RECORD LABEL 1
490 P110280 . SOFTWARE VERSION LABEL 1
500 P111405 . IDENTIFICATION LABEL 1
510 200000163 . ESD LABEL 1
520 SA112100 · CRASH BOX ASSEMBLY 1
530 P109863 . REFLECTIVE SHEET 2
540 P109864 · REFLECTIVE SHEET 2
-550 500000039 . 222 LOCTITE SCREWLOCK AR
- Item Not Illustrated 'AR' As Required 'RF' For Reference Only
