DATA ACQUISITION FLIGHT RECORDER Type D51615-202-XXX or D51615-
202-XXX-090 with CCU Type D51616-XXXX and CAM Type D51623-XXXX
Installation and Operating Manual with Illustrated Parts List
Commercial in Confidence
PIM434-I
© Penny & Giles Aerospace Ltd. No part of this work may be reproduced or distributed by any
means without prior permission in writing from the copyright owner.
Airline Nomenclature Eff Units
Fig/Item Part No Part No Code per
No 1234567 Assy
13-
190 P109324 · COVER, END 1
ATTACHING PARTS
200 435751018 · SCREW, M2.5 PAN HD POZI, 4
8mm LG
205 680125000 · WASHER, M2.5, STD, SS (VK7766) 4
* * *
210 P109719 · GASKET, CONNECTOR 1
220 P110360 . PLATE SPACER 1
230 SA109567-3 · PEC, MEMORY DAUGHTER BOARD 1
(ESD)
ATTACHING PARTS
240 435750891 · SCREW, M3 PAN HD, SS, 4mm LG 4
(VK7766)
* * *
250 480230224 · SPACER, M3, MALE-FEMALE, 4
5mm LG
260 P109703 · BRACKET,CONNECTOR,TOP 1
270 P109702 · BRACKET,CONNECTOR,BOTTOM 1
ATTACHING PARTS
280 435450622 · SCREW, M3 CSK HD, SS, 6mm LG 4
(VK7766)
* * *
290 SA110592 · PEC, SYSTEM (ESD) 1
ATTACHING PARTS
292 435751034 . SCREW, M2.5 POZI PAN HD, 10mm LG 2
294 680125000 · WASHER, M2.5, STD, SS (VK7766) 2
296 P110309 . SPACER 2
300 435886025 · SCREW, M3 BUTTON HD SKT, SS, 4
10mm LG (VK7766)
310 435886015 · SCREW, M3 BUTTON HD SKT, SS, 10
6mm LG (VK7766)
* * *
320 SA109875 · POWER SUPPLY BOARD 1
ASSEMBL Y (ESD)
ATTACHING PARTS
330 W107625/M2.5 · NUT, M2.5, NORMAL, SS (VK7766) 2
340 680125000 · WASHER, M2.5, STD, SS (VK7766) 2
350 W107624/2510 · SCREW, M2.5 CSK, SS, 10mm LG 2
- Item Not Illustrated 'AR' As Required 'RF' For Reference Only
