DATA ACQUISITION FLIGHT RECORDER Type D51615-202-XXX or D51615-
202-XXX-090 with CCU Type D51616-XXXX and CAM Type D51623-XXXX
Installation and Operating Manual with Illustrated Parts
List
Commercial in Confidence
PIM434-I
© Penny & Giles Aerospace Ltd. No part of this work may be reproduced or distributed by any means
without prior permission in writing from the copyright owner.
Figure 1 Data Acquisition Flight Recorder Type D51615-202-XXX
Figure 2 Data Acquisition Flight Recorder Type D51615-202-XXX-
090 Fitted with the (90-Day Beacon Kit
The DAFR is capable of downloading stored flight data, audio,
rotor speed and configuration data digitally at high speed
across the 10Base-T/100Base-Tx Fast Ethernet Manufacturer’s
Test Interface (MTI).
GUARANTEE
VOID LABEL
IDENTIFICATION LABEL
ESD LABE
SOFTWARE
VERSION
LABEL
MOD
RECORD
LABEL
ULB
SWITCH
ULB
