Mar 2017 Page 76
© Penny & Giles Aerospace Ltd. No part of this work may be reproduced or distributed by any
means without prior permission in writing from the copyright owner.
DATA ACQUISITION FLIGHT RECORDER Type D51615-202-XXX or D51615-
202-XXX-090- with CCU Type D51616-XXXX and CAM Type D51623-XXXX
Installation and Operating Manual with Illustrated Parts
List
Commercial in Confidence
PIM434-I
Part No - Column 2
The Part Number column contains the original manufacturers
part number, whether that manufacturer be the prime
manufacturer (Penny & Giles) or a vendor source.
Airline Part No - Column 3
This column is provided for airline use.
Nomenclature - Column 4
In this column the parts are described and the unit is broken
into its subassemblies and detailed parts. Entries in the
Nomenclature column are indented to indicate item
relationship as follows:
1234567
Main Assembly (Reference Item)
Attaching Parts or Installation of Main Assembly
***
Detail Parts for Main Assembly
Attaching Parts for Detail Part
***
. Sub-assembly
. Attaching Parts for Sub-assembly
***
. . Detail Parts for Sub-assembly
. . Attaching Parts for Detail Part
***
Attaching parts are listed immediately below the same
indentation level as the part grouping or assembly to which
they attach. A separation symbol consisting of three asterisks
(***) follows each listing of attaching parts.
Effectivity (Eff) - Column 5
The Effectivity column shows, by a series of letter codes, the
interchangeability of items between equipment variants. An
open effectivity column indicates that there is complete
interchangeability between all equipment variants.
