Curtiss-Wright EXLAR Tritex II AC - Drive Specification for All Tritex 240 Volt Models

Curtiss-Wright | Tritex II AC 90, 115 Rev. X PN39892 7/12/22
22
Drive Specification for all Tritex 240 Volt Models
Drive Specifications
Input Voltage, Bus
and Logic
100 to 240 Volts ac nominal +/-10%
Control Logic
supply (Optional)
24 V dc +/- 10% - Class 2 or isolating source pro-
tected by 4A maximum fuse 0.5 A dc max load
I/O Power Supply
24 V dc +/- 10% - Class 2 or isolating source
protected by a 4A maximum fuse
Enclosure Rating
UL Type 4 and IP:66
Digital Inputs
8 – opto isolated, 12 to 30 V dc for ON state, 0 to
1V dc for OFF state, common return at “I/O
Power Supply” “common” terminal
Programmable functions
Digital Outputs
4 – opto isolated 100 mA continuous, short circuit
protected, powered from “I/O Power Supply” with
1V maximum drop from supply voltage,
programmable functions
Analog Input
0-10 Volts or +/- 10 Volts differential input, 12 bit
resolution, programmable as position, velocity or
torque command
Analog Output
0-10 Volts at up to 20 mA, 12 bit resolution,
programmable function
Serial Interface
Optically isolated RS-485, Modbus RTU protocol,
38.4kbaud max
Commutation
Sinusoidal, 10kHz PWM
Position
Resolution
0.001 revolution (with analog hall feedback)
Accuracy
+ / - 0.002 revolution (with analog hall feedback)
Environmental
Ambient Temperature, charts below show
ratings for 25° C
Maximum Operating temperature
range -20° to 65° C
See de-rating chart for temperatures above 25° C.
For operation below -20°C contact Exlar
Applications Engineering.
Actuator Selections
(This manual applies to 90mm and 115mm frame sizes only)
