Curtiss-Wright | Tritex II AC 90, 115 Rev. X PN39892 7/12/22
CE Declaration of Conformity
The Tritex II Linear and Rotary Actuators are marked with the
“Conformité Européenne Mark” (CE Mark) after passing a rigorous set of
design and testing criteria. This label indicates the product meets
applicable electrical safety, and electromagnetic immunity and emissions
(EMC) standards when installed according to the installation instructions.
The conditions of acceptability required for CE are:
• Drive input maximum continuous operating ratings:
Input Voltage (all models): 240 VAC, 1 Ф, 50/60 Hz
Input Continuous
Current (Arms)
• L1, L2, PE: For input terminals maximum 14 AWG/ 2.5mm² wire
shall be used but not less than 125% of the maximum current for
the input.
• Wires ends are to be solid for input terminal connections. When
stranded wire is used tin the wires or a similar method should be
used to prevent stray strands of wire.
• Do not strip wires more than 0.25 inch (6.3 mm) for input
terminal leads.
• Use 300VAC minimum rating, and 105º C minimum rating
copper wires
• An externally connected ground wire must be used. Single rear
screw connection, screw. Must be earthed (grounded) for safety,
minimum wire size 2.5mm². Adequate strain relief and
mechanical protection must be provided for this wire. Note, this
does not replace and is used in addition to the 2.5mm² grounding
conductor that is connected to the input power terminals.
• If used, the +24 VDC Control Logic power supply and/or the I/O
power supply must be a CE marked 24V supply and negative
side must be connected to PE.
• This product is suitable for use on a circuit capable of delivering
5,000 rms symmetrical amperes, 240 volts maximum, when
protected with by a Class RK1 or Class CC fuse or Inverse Time
Circuit Breaker, rated at 15 A rms.
