Curtiss-Wright EXLAR Tritex II AC - Specifications: Size 90 Linear Actuators

Curtiss-Wright | Tritex II AC 90, 115 Rev. X PN39892 7/12/22
23
Tritex actuators are available in linear, rotary, and rotary with
integrated planetary gearing in both 90 mm and 115 mm frame sizes. All
include embedded drive and motion controller.
Frame Size
Linear
Rotary Motor
Rotary
Gearmotor
Std. Capacity
High Capacity
90 mm
T2M-090
T2X-090
R2M-090
R2G-090
115 mm
T2M-115
T2X-115
R2M-115
R2G-115
Specifications: Size 90 Linear Actuators
T2M/X090
Stator 1 Stack 2 Stack 3 Stack
Lead
RPM @ 240 VAC
4000
4000
3000
0.1
Continuous Force
lbf (N)
1,130 (5062)
1,488 (6619)
NA
Peak Force
lbf (N)
2,260 (10053)
2,700 (12010)***
NA
Max Speed
in/sec (mm/sec)
6.67 (169)
6.67 (169)
NA
T2X - C
a
(Dynamic Load Rating)
lbf (N)
5516 (24536)
NA
T2M - C
a
(Dynamic Load Rating)
lbf (N)
3310 (14724)
NA
0.2
Continuous Force
lbf (N)
640 (2847)
843 (3750)
1,113 (4951)
Peak Force
lbf (N)
1,281 (5698)
1,687 (7504)
2,225 (9897)
Max Speed
in/sec (mm/sec)
13.33 (338)
13.33 (338)
10.00 (254)
T2X - C
a
(Dynamic Load Rating)
lbf (N)
5800 (25798)
T2M - C
a
(Dynamic Load Rating)
lbf (N)
3570 (15880)
0.5
Continuous Force
lbf (N)
271 (1205)
357 (1588)
471 (2095)
Peak Force
lbf (N)
542 (2410)
714 (3176)
942 (4190)
Max Speed
in/sec (mm/sec)
33.33 (846)
33.33 (846)
25.00 (635)
T2X - C
a
(Dynamic Load Rating)
lbf (N)
4900 (21795)
T2M - C
a
(Dynamic Load Rating)
lbf (N)
3016 (13416)
Drive Current @ Continuous Force
Amps
5.7
7.5
7.5
Available Stroke Lengths
in (mm)
3 (75), 6 (150), 10 (254), 12 (300), 18 (450)
Inertia (zero stroke) lb-in-s
2
/ Kg-m
2
0.002655
(0.000003000)
0.002829
(0.000003196)
0.003003
(0.0000033963)
Inertia Adder (per inch of stroke)
lb-in-s
2
/in/ Kg-m
2
/in
0.0001424 (0.0000001609)
Approximate Weight lb (kg)
14 (6.35) for 3 inch stroke, 1 stack. Add 1 (0.5) per inch of stroke.
Add 3 (1.4) per motor stack. Add 3 (1.4) for brake.
Operating Temperature Range
*
-20 to 65˚ C (-40˚C available, consult Exlar)
Continuous AC Input Current
**
Amps
6.3
6.3
6.3
Ratings based on 25˚C conditions. ** Continuous input current rating is defined by UL and CSA.
*** T2X peak force for 0.1 inch lead is 2700 lbf (12010 N). T2M peak force for 0.1 inch lead limited to 1620 lbf (7206 N).
