COP Option
Ethernet Options, EIP or TCP or ProfiNET
The Ethernet Option provides an Ethernet rated M12 connector for
connection to the Network at the rear of the actuator.
An IP 67 4-pole M12 D coded connector is used, this type of connector
must only be used with 2 pair cables. When the Ethernet connection is
via an Ethernet switch or hub, a straight though cable set must be used.
If there is single node connection direct from the Ethernet PC/PLC to the
Tritex then a crossover cable must be used. See Expert Software section
for setup of Tritex Ethernet parameters.
Cord sets
M12 D Coded Straight Through Cord Set
Signal
M12
Pin
Color
CONN 1
Pin
CAN H
4
White
1
CAN L
5
Blue
2
Shield
1
Gray
3
Pin
Signal Name
1
Transmit + (TX+)
Pair
3
Transmit – (TX-)
2
Receive + (RX+)
Pair
4
Receive - (RX-)
1
2
3
4
1
3
4
2
1
